A-Frame Cabins

  • Our A-Frame takes our standard cabin layout and elevates it with a classic, steep 12/12 pitch roof. Complete with a 4-foot side porch and heavy-duty construction, it’s the ultimate retreat for lakeside weekends or overnight hunting trips.

  • Porch & Footprint

    • Built-in Porch: Features an additional 4' side porch with a 4/12 roof pitch.

    • Sizing Note: The 4' porch is added to the base width of your cabin (e.g., a 10’x16’ cabin has a total footprint of 14’x16’).

    Heavy-Duty Framing & Floors

    • Premium Flooring: 2″x6″ tongue-and-groove (T&G) treated floors.

    • Tall Walls: 87” (7’ 3″) wall height for excellent headroom.

    • Sturdy Studs: 16″ O.C. wall studs (on Premier, Vinyl Series, and Horizontal siding builds).

    • Reinforced Openings: Headers above all doors for superior structural integrity.

    Doors & Access

    • Primary Entry: 32 ¾” single entry door located on the porch.

    • Double Doors: 10’-16’ wide units include spacious 67”x 72″ double doors.

    • Rugged Construction: All doors are double-framed and assembled with screws for maximum durability.

    • Protected Thresholds: 3″ aluminum tread plates included in all doorways.

    Roofing & Exterior Finishing

    • Steep Roofline: Classic 12/12 roof pitch with a 7″ eave overhang.

    • Premium Shingles: 30-year dimensional shingles over sturdy 5/8″ plywood roof sheathing.

    • Weather Protection: Aluminum drip edge along all roof edges.

    • Superior Airflow: Full ridge vent included standard.

    • Elegant Trim: Beautiful 1″x6″ cedar fascia.

    Note: Looking to customize your build? Check out the Options tab for all the extras you can add!

  • Applies to Premier, Pine, and Vinyl Series

    • 10’W x 20’L: 14’ 2” Peak Height

    • 12’W x 20’L: 15’ 2” Peak Height

    • 14’W x 20’L: 16’ 2″ Peak Height

    • 16’W x 24’L: 17’ 2” Peak Height
